Sander[CT-1548BS]
DOWNLOAD
Benchtop Sander
| SPECIFICATIONS | |||||
|---|---|---|---|---|---|
| 15” | 20” | 15” | 20” | ||
| Motor | 1.75HP 120V 60HZ 1PH | 3HP 230V 60HZ 1PH | Sanding Belt Length | 16” x 48” | 21” x 48” |
| Maximum Sanding Board Width | Single pass: 15” Double pass: 30” |
Single pass: 20” Double pass: 40” |
Conveyor Belt Length | 15” x 48” | 20” x 48” (PVC) |
| Maximum Board Thickness | 4” | 4” | Sanding Belt Speed | 2800 FPM | 2800 FPM |
| Minimum Board Thickness | 1/32” | 1/32” | Conveyor Motor | 1/30HP 100VDC 44RPM 0.27AMP | 65W 180VDC 40RPM |
| Minimum Board Length | 8” | 8” | Conveyor Speed | 0~10 FPM | 0~15 FPM |
| Drum Diameter | 6” | 6” | Oscillation Motor | 1/30HP 100VDC 44RPM 0.27AMP | 1/30HP 200VDC 44RPM 0.27AMP |
| Drum Speed | 1800 RPM | 1800 RPM | Oscillations per Minute | 20 cycle | 20 cycle |
| Drum Length | 15” | 20” | Dust Port Diameter | 4” | 4” |
| Idler Wheel O.D. | 5” | 5” | Net Weight | 211.65 lbs / 96 kgs | 507.0 lbs / 230 kgs |
